Automatic Vial Filling, Stoppering & Capping Machine
Single-head rotary machine that unscrambles, fills, stoppers, caps and crimps vials automatically: 3–30 mL at 40–50 vials per minute fully stoppered. Peristaltic filling with easy cleaning.
- With enclosure & HVAC
- Integrated horizontal laminar-flow hood with H14 HEPA, designed for ISO 5
- Without enclosure
- For placement under your existing ISO 5 hood
Specifications
- Process
- Vial unscrambling → filling → stopper insert & press → cap placement → pneumatic crimp → discharge
- Fill volume
- 3–30 mL (uniform vial diameter per run)
- Fill accuracy
- ±1% (under 0.02 g error at 1 g)
- Speed
- 40–50 vials/min fully stoppered · 30–35 vials/min half-stoppered, depending on material and fill volume
- Filling method
- Peristaltic pump as standard (aqueous, oil-based and non-viscous products); ceramic piston pump for low-to-medium viscosity
- Filling head
- 1 head, 316L stainless steel
- Drive
- Siemens servo indexer with automatic reset
- Controls
- Siemens PLC & touchscreen · Honeywell relays & switches · Airtac solenoid valves
- Height changeover
- Under 60 seconds
- Power
- 8 kW · 220 V, 50/60 Hz
- Compressed air
- 0.45–0.6 MPa
- Dimensions (L × W × H)
- 1710 × 1660 × 2260 mm · 800 kg
- Materials
- 304 SS cabinet · 316L SS product-contact parts
- Safety
- Auto-stop on missing vial, stopper or cap
- Options
- Cap-seal vision inspection, container-closure integrity testing, 100% check-weigh (priced separately)
- Warranty
- 1 year machine · 2 years motor & touchscreen
The laminar-flow enclosure is an open horizontal-flow hood designed for Grade A / ISO 5 conditions that support aseptic processing, subject to on-site qualification. Qualifying the installed machine is the facility’s responsibility; we supply an IQ/OQ plan to support it.
Estimate with your numbers
An estimate from the numbers you enter, not a quote.
- Monthly filling labor today
- $17,500
- With one operator on the Auto Filler
- $3,500
- Monthly labor freed up
- $14,000
- After a $4,000 / month lease
- $10,000
- Equipment option at this volume
- Purchase or lease
Supplies, labeler and wear parts
Horizontal Vial Labeling Machine
Connects to the Auto Filler discharge
Silicone peristaltic tubing
Auto Filler wear part
Capping head
Auto Filler wear part
Vials, stoppers & caps
2R–10R vials, 13 / 20 mm closures
Installation and commissioning within 90 days of order.
Setup, height changeovers in under a minute, cleaning and alarm response.
One vial diameter per setup; confirm stopper and cap materials in advance.
Auto Filler questions
How fast is the Team 4 Auto Filler?
40–50 vials per minute fully stoppered and 30–35 vials per minute half-stoppered, for fill volumes of 3–30 mL with ±1% filling accuracy. Actual speed depends on the material and fill volume.
Can the Auto Filler run inside my existing cleanroom?
Yes. Order it with its own enclosure, HVAC and H14 laminar-flow hood designed for ISO 5, or without an enclosure for placement under an existing ISO 5 hood. Either way, the installation is qualified on site.
How can I finance an automated vial line?
Purchase outright, lease for $4,000 per month over 36 months, or pair the equipment with a 2-year vial supply commitment: at 250,000 vials per month there is no equipment charge.
Price an automated vial line.
Tell us your vial formats, fill volumes and monthly output. We return configuration, pricing options and a 90-day deployment plan.
